In AP mode, Ameba can accept at most 3 station connections, and can be set to open mode or WPA2 mode.

In AP mode, Ameba can accept at most 3 station connections, and can be set to open mode or WPA2 mode.

RTL8722DM_MINI

Ameba RTL8722DM is a low-power dual-band WLAN and Bluetooth Low Energy SoC by Realtek. The RTL8722DM also include memory for Wi-Fi protocol functions and application making it simple for anyone to develop various kind of IoT applications. At the same time it has a wide range of peripheral interfaces. With all these interfaces, it can connect to most of the electronics components like LEDs, temperature and humidity sensors, and so on.

More Resources:

If you need additional technical documents or the source code for this project. Please visit the official websites and join the Facebook group and forum.

Ameba Official Website: https://www.amebaiot.com/en/

Ameba Facebook Group: https://www.facebook.com/groups/amebaioten

Ameba Forum: https://forum.amebaiot.com/

Setup

In this example, we turn on the AP mode of Ameba and connect station to Ameba.

Open the WiFi AP example, “File” -> “Examples” -> “AmebaWiFi” -> “WiFiAPMode”


Final Result

Then upload the sample code and press reset, and you can see related information shown in serial monitor.
